LED Rock Lights
LED Rock Lights
Sale price Price: $47.00 USD
You Save: $0.00 USD
Select Popular Add Ons
Couldn't load pickup availability
IP69K Sealed · 8 Colors · Black or White Housing
LED Rock Lights
Compact, sealed LED rock lights for wheel wells, sliders, bumpers, and undercarriages. Each light puts out up to 495 lumens through a 120° wide beam, runs on 10–30V DC, and is rated IP69K for mud, dust, water crossings, and the pressure washer.
IP69K WaterproofOsram LEDs10–30V DCLimited Lifetime Warranty
495 lmWhite Output
IP69KWaterproof
0.35ADraw Per Light
50,000Hour Life
Pick Your Look
8 light colors, 2 housing colors
Black housing for a stealth look on frames, sliders, and skid plates. White housing for lighter builds and interiors.
WhiteBrightest at 495 lm. Lights up the trail, tire lines, and camp. Amber
Warm, classic trail glow that cuts through dust. Red
Aggressive look that keeps your night vision at camp. Blue
The show-rig favorite. Makes the whole underbody pop. Green
A bold color that stands out at every meet-up. Amber & White (3 Wire)
Two colors in one light. Wire each to its own switch. RGB
Any color from your phone. Requires an RGB controller. Ultraviolet (UV)
Makes fluorescent paint and decals glow after dark. Built For The Trail
Small light, trail-tough build
IP69K Sealed
Rated against high-pressure, high-temperature water jets. Mud, dust, water crossings, and the car wash don't get in.
Osram LEDs, 120° Beam
Three Osram diodes throw a wide, even wash of light across the ground and into the wheel wells.
Vibration-Damping Mount
A rubber mounting seat soaks up trail chatter and impacts, and stainless hardware won't rust out.
Going RGB?Pair it with our IP67 Bluetooth controller
RGB lights need a controller. Ours is sealed to IP67, runs two 10A zones on 12V or 24V, and works from the free Black Oak LED app.
RGB ControllerRGB Wire
Made for the Harshest Conditions
Rock lights live in the worst spot on the rig. Ours are sealed to IP69K, rated from -40° to 145° F, and tested for impact, weight, and extreme weather. Run them through mud, sand, snow, and creek crossings, then hit them with the pressure washer when you get home.
Wire It Your Way
No pre-cut harness means no extra wire to hide and no coming up short. Each light has a 4 ft lead, so add exactly what you need (18 AWG recommended). Run them on our dimmer switch with remote, our standard wiring harness, or a switch you already have.
Small Size, Big Impact
At 0.35A per light, you can run a full set on one circuit. Mount them in wheel wells, under bumpers and sliders, or along the frame of Jeeps, crawlers, trucks, UTVs, golf carts, and trailers. The low-profile housing tucks in where bigger lights won't fit.
Power & Performance
| Wattage | 9W |
|---|---|
| Amp Draw | 0.35A |
| Operating Voltage | 10–30V DC |
| Lumens | 495 (White) 220 (Red, Blue, Green, Amber, RGB) |
| LEDs | 3 × Osram |
| Beam | Wide angle, 120° |
| Mode | All on |
Durability & Warranty
| Waterproof Rating | IP69K |
|---|---|
| Operating Temp | -40° to 145° F (-40° to 62° C) |
| Life Expectancy | 50,000 hours |
| Warranty | Limited lifetime |
| Guarantee | 30-day money back |
Wiring & Installation
| Lead Length | 4' |
|---|---|
| Wire Gauge | 22 AWG (18 AWG recommended for extensions) |
| Connector | Open-end wire lead |
| Harness Included? | No |
| Recommended Fuse | 5A |
| Mounting | Rubber seat + stainless hardware (included) |
General & SKUs
| Weight | 0.35 lb |
|---|---|
| Black Housing | RL-W · RL-A · RL-R · RL-B · RL-G · RL-AW · RL-RGB · RL-UV |
| White Housing | MAL-W · MAL-R · MAL-B · MAL-G · MAL-RGB · MAL-UV |
With 4' 22 AWG lead 1 × Rubber Mounting Seat
Damps vibration and seals the base Stainless Steel Bolt Kit
Corrosion-resistant mounting hardware Quick Start Guide ↗
Wiring and mounting steps (PDF)
Do these come with a wiring harness or switch?
No. Each light has a 4 ft open-end lead that you wire to your own switch and fuse (5A recommended). Our dimmer switch and standard wiring harness both work great. For RGB lights, wire them to an RGB controller instead.
Will they work on a 24V system?
Yes. They run on anything from 10V to 30V DC, so 12V and 24V vehicles both work with no changes.
How many can I run on one circuit?
Each light draws 0.35A, so a set of 8 draws about 2.8A. Size your fuse and wire to the total draw of everything on the circuit.
What do I need to run the RGB version?
An RGB controller. Our IP67 Bluetooth RGB controller runs them from your phone. For longer runs, add RGB wire by the foot.
Are rock lights street legal?
They're made for off-road and private property use. Some areas restrict certain colors on public roads, so check your local laws. When in doubt, save them for the trail and campsite.
Can I mix colors?
Absolutely. Mix and match colors to build your own setup. If you want to change colors on the fly, go with RGB and a controller.
What does IP69K actually mean?
IP69K is the toughest standard rating for dust and water. The light is tested against close-range, high-pressure water jets at up to 176° F (80° C), so mud, dust, and pressure washing are no problem.
What does the warranty cover?
Our limited lifetime warranty covers workmanship and material failures. Send the light back and once we verify the issue, we'll repair or replace it free of charge. Every order also comes with a 30-day money-back guarantee.
